Loader 300

COMPOSITION OF THIS KIT:
1 loader 300
This model is compatible with our capsulefiller, the FMT300.
───────────────────
COMPATIBLE CAPSULE SIZES:
4,3,2,1,0,00
Capsules available at Feton.
───────────────────
INFORMATIONS:
- Manufactured in certified plastic (POM)
- Frame made in one piece
- Machine washable up to 40°C

- 2-step loading
- Clean operation: no manual handling of capsules
───────────────────
HOW TO USE:
Video demonstration
1. Prepare your material: Capsule Loader, Capsule Filler, Capsules, Powder.
2. Pour capsules in the loader and shake it from side to side to fill all holes with an empty capsule.
3. Remove the excess of capsules.
4. Place the loader in the positioning slots. The loading is done in two steps: slide the loader either towards you or away from you.
5. Push the loader handle. The capsules should fall upright into the top plate.
6. If a capsule in blocked in the loader, push the handle and the lock button to keep the loader in “open” position. Then use a Feton Teflon stylus to move the capsule without risk of damaging the loader.
7. Repeat steps 2-3-4-5-6
8. Your capsule filler is now ready for use.
